Benford’s law: learning to fraud or to detect frauds?

Posted on May 24, 2015 by admin

Originating author is Christiane Rousseau.
It is very risky to change too many numbers in some fi nancial statements if one does not know some mathematics. Indeed, most often the numbers appearing in fi nancial statements follow some strange mathematical rule, called Benford’s law, or law of the fi rst signi ficant digit. If one forgets to follow the rule, then the numbers will fail some statistical tests and are likely to be scrutinized with care. Benford’s law claims that if you collect numbers at random and calculate the frequencies of their fi rst signifi cant digits, the numbers with fi rst signifi cant digit 1 should appear around 30% of the time, while the numbers with fi rst signifi cant digit 9 appear only 4.5% of the time. This rule is observed in many other sets of numbers, like powers of 2 or Fibonacci numbers.

Why?

We now have satisfying explanations. We are going to share them with you.

Benford law’s concerns the distribution of the fi rst signi ficant digits of numbers. The fi rst signi ficant digit of a positive number is the leftmost nonzero digit of its decimal expression. For instance, the first signifi cant digit of \pi% is 3, that of 2371.5 is 2, and that of 0.00563 is 5. Another way to de fine it which will be useful for our mathematical discussion is to write a positive real number x as a number m \in [ 1 , 9 ) times a power of 10:

    \[x = m 10^n ~ , ~~ n \in \mathbb{Z}.\]

Then the first signi ficant digit of x is the integer part of m, which can be denoted by \lfloor m \rfloor. The number m is called the mantissa of x. We now claim that if you collect numbers at random and compute the frequency B(i) of the fi rst signifi cant digit i, then B(i) is approximately given by \log_{10} (1 + \frac{1}{i}). This gives us the frequencies:


Rendered by QuickLaTeX.com

Table 1: Frequencies of Benford’s law.

Figure 1: Frequencies B(i) of Benford’s law.

Let us now give a very brief historical note. The phenomenon was first discovered by the astronomer Simon Newcombe (1835-1909) who noticed that the fi rst pages of the logarithmic tables corresponding to small fi rst signifi cant digits looked much more worn than the later pages. His discovery was forgotten and the law was rediscovered by Frank Benford (1883-1948) around 1938. Frank Benford collected tenths of thousands of numbers from all origins following his law. The modern data base of Simon Plouff e which contains 215 millions mathematical constants also follows Benford’s law.

Many sets of numbers that are not random also follow Benford’s law. This is the case with the populations of countries, with the areas of countries, with the length of rivers, etc. Maybe you will stop me and start being skeptic… In which units are these lengths or areas collected? Are lengths in miles or in kilometers? This does not matter… If the lengths of rivers in kilometers follow Benford’s law, then the lengths in miles follow Benford’s law! A change of unit corresponds to a change of scale. We will see that Benford’s law is invariant under change of scale. Moreover, it is the only probability law which is invariant under change of scale.

Figure 2: Some data approximately following Benford’s law: areas of countries in
square kilometers, areas of countries in square miles, and populations of countries.

I told you in the introduction that the Fibonacci numbers follow Benford’s law. But, in a sense, Benford’s law is subjective, since it depends on the basis 10 in which we write our numbers. In some basis b with b \neq 10, the nonzero digits are the elements of the set \{ 1; ... ; b-1\}, and Benford’s law in basis b says that the frequency of the first signifi cant digit i is B_b (i) = \log_b (1+\frac{1}{i}). Well! Fibonacci numbers follow Benford’s law in any basis b! Benford’s law is invariant under change of basis. And it is the only non trivial probability law which is invariant under change of basis.

Now it is time to come to explanations. They will require that you remember some of your probability course. But you could prefer to experiment by yourself first before starting reading more serious maths.

1. Invariance under change of scale

Let us consider a simple change of scale obtained by multiplying all numbers of a set of numbers by 2. If we consider the numbers with fi rst signifi cant digit 1, then they are changed to numbers with first signifi cant digit either 2 or 3. It is easy to check that B(1) = B(2) + B(3). Indeed,


Rendered by QuickLaTeX.com

Similarly, you could check that B(2) = B(4)+B(5), etc. But how do you manage if you change from miles to kilometers, i.e. multiply numbers by 1.6? As stated, Benford’s law is too restrictive and we need to generalize it. What does it mean that the first signifi cant digit is i? It means that the mantissa m belongs to the interval [i, i + 1). So, Benford’s law is a partial probability distribution on the mantissa. The generalized Benford law (which, by abuse of language, we will call Benford’s law) on the mantissa is given by a density function on the interval [1, 10). When we pick up a number at random, we can compute its mantissa. This gives us a random variable M taking values in [1, 10). We say that it follows Benford’s law if its density function is given by

    \[f(x) = \left\{ \begin{array}{ll} \frac{1}{x \log 10}, & x \in [1 , 10 ), \\ 0, & \mbox{otherwise.} \end{array}\right.\]

If P(a \leqslant M < b) represents the probability that a \leqslant M < b, then this means that we must have

    \[P( a \leqslant M < b ) = \int_a^b f(x) d x.\]

It is really a generalization of Benford’s law since


Rendered by QuickLaTeX.com

What does it mean to say that a random variable X on [1, 10) is invariant under change of scale? It means that, if c is a positive real number and if we take the random variable Y = cX, then the mantissa M of the random variable Y has the same density function as X. It is not difficult to show that this is the case when X follows Benford’s law, but there are several cases to distinguish depending on the size of c. We will do one case and will let you do the other cases. We can write c = m 10^r, with m \in [1, 10) the mantissa of c. Since the mantissa of cX is the same as that of mX, it suffices to consider the case c \in [1, 10).
What is the tool to show that? You may remember from your probability course that the (cumulative) distribution function is sometimes more useful than the density function for a continuous random variable. The distribution function of a random variable M is
defi ned as

    \[F(x) = P(M \leqslant x).\]

If X follows Benford’s law, then its distribution function is given by

(1)   \begin{eqnarray*} F(x) = \left\{ \begin{array}{ll} 0, & x < 1, \\ \log_{10} x, & x \in [1 , 10), \\ 1, & x \geqslant 10. \end{array}\right. \end{eqnarray*}

So we must show that if X follows Benford’s law and M is the mantissa of cX for c \in [1, 10), then the distribution function of M is given by (1).

For that purpose, we need to calculate P(M \leqslant z) for z \in [1, 10]. M is the mantissa of cX which takes values inside [c, 10c). So M = cX, when cX < 10 and cX / 10 when cX \geqslant 10. The first case occurs when z < c. For the mantissa of cX to lie inside [1, c), the only possibility is that cX \in [10, 10c]. Then the mantissa of cX is equal to cX / 10.
Hence,


Rendered by QuickLaTeX.com

as expected. The other cases are done in the same way.

The reciprocal is more exciting…

2. Benford’s law is the only probability law on the mantissa which is invariant under change of scale

It seems an impressive statement! Yet, you will see that its proof is not much more complicated than the previous argument. Let X be a random variable representing the mantissa and taking values inside [1, 10). We look for its distribution function F(x), under the hypothesis that X is invariant under change of scale. So we need to compute

    \[F(x) = P(X \leqslant x) = P(1 \leqslant X \leqslant x).\]

Hence, we must have F(0) = 0 and F(10) = 1.
The main difficulty of the proof lies in interpreting what it means that X is invariant under change of scale. Since 1 \leqslant X \leqslant x and c \leqslant cX \leqslant cx are the same events, then we have that

(2)   \begin{eqnarray*} P(1 \leqslant X \leqslant x) = P(c \leqslant cX \leqslant cx) = F(x). \end{eqnarray*}

As before, let us consider the case of some c \in [1, 10) so that cx < 10 (c depends on x). Then, for c \leqslant cX \leqslant cx, cX is equal to its mantissa. Since X is invariant under change of scale, then the mantissa of cX has the same distribution function as X. Hence,

    \[P(c \leqslant cX \leqslant cx) = F(cx) - F(c).\]

Combining with (2) we see that F(x) satisfi es

(3)   \begin{eqnarray*} F(x) = F(cx) - F(c),~~~ F(1) = 0,~~ F(10) = 1. \end{eqnarray*}

provided that c \in [1, 10) is not too large. We must find F from the functional equation (3). Let’s see how to do this. If we let c = 1 + \varepsilon, this yields

    \[F(x) = F(x(1 + \varepsilon)) - F(1 + \varepsilon)\]

which can be written

    \[\frac{F(x(1 + \varepsilon)) - F(x)}{x \varepsilon} = \frac{F(1 + \varepsilon) - F(1)}{x \varepsilon},\]

since F(1) = 0. Let us take the limit when \varepsilon \longrightarrow 0. We must recognize on each side a quotient whose limit is a derivative. On the left side it is \frac{F(x + x \varepsilon) - F(x)}{x \varepsilon}, the limit of which is F'(x), and on the right side it is \frac{F(1 + \varepsilon) - F(1)}{\varepsilon} which tends to F'(1). Hence, we get the
diff erential equation with separable variables

    \[F'(x) = \frac{F'(1)}{x},\]

the solution of which is F(x) = F'(1) \ln x + C. Since F(1) = 0 we have C = 0, and since F(10) = 1, then F'(1) = \frac{1}{\ln 10} . Hence, F(x) = \frac{\ln x}{\ln 10} = \log_{10} x and we are done!

3. Why numbers collected from all origins follow Benford’s law?

An answer was provided by Theodore Hill in 1995, and we will discuss briefly his idea. Of course, not all sets of numbers follow Benford’s law. For instance, if you consider the height of humans in meters then, up to a few exceptions, only the first signifi cant digits 1 and 2 will occur, and if you convert the size in feet (a foot is approximately 30 cm) you will change the distribution law of the fi rst signifi cant digit. So this set of numbers is not invariant under change of scale. But, suppose we consider a large set of numbers coming from all origins and we change of scale. There are diff erent subsets of numbers with their particular scale. Because the set is large and the numbers come from all origins then, most likely all diff erent scales are present. Multiplying all numbers present in the set by a positive constant induces a permutation of the scales present in the new set. So, as a whole, we could expect the set of numbers to behave as if it had no special scale. Hence, it will follow Benford’s law.

This explanation is good for sets of numbers coming from all origins. But it does not explain why areas of countries, populations of countries, or lengths of rivers should follow Benford’s law. We will discuss very recent explanations (2008!) for this case given by Gauvrit, Delahaye and Fewster. Their explanation is also valid for large sets of numbers coming from all origins.

4. Sets of numbers spreading over several orders of magnitude are likely to follow Benford’s law!

We are working in base 10 and we have seen that positive numbers x can be written as x = m 10^n, where m \in [1, 10) and n \in \mathbb{Z}. We could consider n as the order of magnitude and we say that there are several orders of magnitude if there are several values of n for our set of numbers. (Note that such a property is invariant under change of scale!) To simplify the explanation, suppose that the numbers lie within [1, 10^6). Then the numbers with signi cant digit 1 are the ones in the set

    \[S_1 = [1, 2) \cup [10,20) \cup [100,200) \cup [1000, 2000) \cup [10^4 , 2 \times 10^4 ) \cup [10^5 , 2 \times 10^5),\]

and similar sets S_i with the other digits. It is better to move to the logarithm in base 10 of these numbers: y = \log_{10} x. Then y = \log_{10} m + n. Let us show that if a random variable M on [1, 10) obeys Benford’s law, then the random variable Z = \log_{10} M is simply uniform on [0, 1). For that, it suffices to show that the distribution function of Z is that of the uniform random variable on [0, 1), namely

    \[F(z) = \left\{ \begin{array}{ll} 0, & z < 0, \\ z, & z \in [0 , 1), \\ 1, & z \geqslant 1. \end{array}\right.\]

Indeed, when z \in [0, 1),

    \[P(Z \leqslant z) = P(0 \leqslant \log_{10} M \leqslant z) = P(1 \leqslant M \leqslant 10^z) = \log_{10} 10^z = z.\]

If X belongs to the set S_1, then Y belongs to the set T_1 = \log_{10} S_1:


Rendered by QuickLaTeX.com

and similarly for the other digits. Suppose that taking a random number in our set is a random variable X taking values inside [1, 10^6). Then Y = \log_{10} X takes values inside [0 , 6). Recall that the probability that some random variable belongs to some set is equal to the area under the graph of the density function over the set. If the density function f of Y over [0 , 6) was uniform as in Figure 3 (a) we would be done. Most often however, it will not be the case as in Figure 3 (b). But this is why it is so important that the original set of numbers is spread over several orders of magnitude. The di fferent portions corresponding to a given fi rst signifi cant digit i are spread horizontally over several segments, whose sum of lengths is of the order of \log_{10} (1 + \frac{1}{i}) of the total width. So, even if the height of f(x) is not the same from one segment to the other, one could hope that the mean height be of the same order of magnitude for the diff erent digits. When this occurs, then the data follow Benford’s law.

(a) density function f uniform
(b) density function f non uniform
Figure 3: The areas corresponding to the frequencies of the first signifi cant digits 1, 2, 3 and 4 for two
diff erent density functions of Y. The values of the corresponding areas are plotted in Figure 4.

(a) density function of f
(b) Areas under the curve for the signi cant digits of f and for the uniform function
Figure 4: The areas corresponding to the frequencies of the first signi cant digits 1, 2, 3 and 4 for the density function of Figure 3(b). On the right we see that these values are pretty close to those obtained by Benford’s law in the case of a uniform density function for Y.

5. How to test if a set of numbers follows Benford’s law?

If you have followed a statistics course, then you probably studied the \chi^2 goodness-of-fi t test. This test allows you to check if some data follow some probability distribution. Suppose you want to make the test with a set of n numbers. You just need to construct a table, in which n_i represents the number of numbers in your set which have first
signi ficant digit i. Of course, n = n_1 + ... + n_9. The N_i represent the numbers of numbers that should have fi rst signifi cant digit i if your set was following Benford’s law, namely N_i = nB(i).


Rendered by QuickLaTeX.com

Table 2: The table for the \chi^2 goodness-of-fi t test.

You then calculate

    \[\chi^2 = \sum \limits_{i=1}^9 {\frac{(n_i - N_i)^2}{N_i}},\]

and you look in a table of the \chi^2 at the line corresponding to 8 degrees of freedom. If you are to make a test with 5% of error, then you accept that the data fit Benford’s law if \chi^2 < 15.51 and you reject otherwise. This is a fast recipe, but if you are to make such tests with your students, then just take some time to get more familiar with the details of the test and its meaning.

6. Invariance of Benford’s law under change of basis

This could be modeled in a similar way as the invariance under change of scale. It is more tricky though, since we cannot limit our work to the mantissa. Indeed, if x = m 10^n, then the part 10^n also need to be converted to the new basis. And, in fact, the main difficulty is to express in mathematical terms what it means for a random variable to be independent under change of basis. We skip the details.

7. Conclusion

Benford’s law is fascinating: it defi es the intuition, and is it something that you can test yourself and also adapt for a classroom activity. It used to be a curiosity, but it is now a standard tool to detect frauds. Of course, more and more tax evaders learn of it. But pay attention: the first signifi cant digit is not the only thing to take care of. The generalized Benford’s law allows to derive a law for the second signi ficant digit, third signifi cant digit, etc. You can try to find it by yourself: just think in which unions of intervals the mantissa of a number should be so that its second signifi cant digit is i.
